Domestic Series
Silent Features
- The rotating parts of motor and pump are dynamically to ensure minimum noise and vibration.
- Capacitor starts and runs motor with IP 44 protection.
- Pre-lubricated double-shielded ball bearings for longer life.
- High quality carbon-ceramic mechanical seal for a longer life.
Applications
- Water supply in house, hospital, RO water treatment, car washing, small farms.
Specifications
| Power Range | 0.5HP To 1HP |
| Suction | Upto 8 MTR |
| Discharge Range | Upto 54 LPM |
| Head range | Upto 36 MTR |
| Speed(RPM) | 2880 |
| Version | 180-230Volts, 50HZ, A/C-1Phase Permanent Split Capacitor (PSC) Incorporated with top. |
Material of Construction
| Name of Parts | Material Used |
|---|---|
| Motor body | Aluminum/ Cast Iron |
| Pump body | Cast Iron FG200 As per IS:210 |
| Impiller | High tensile bronze As per IS:613 |
| Shaft | EN 8 |
